3 Axle Conveyor Belt Dump Trailer

We have high-quality 3 axle conveyor belt dump trailer for sale, YUHANG factory can design and customize dump trailer according to your special transportation needs, to help you do business better.

24500 USD

Model: 3 axle conveyor belt dump trailer

Hydraulic System: HYVA cylinder

Delivery Date: 15-25 days

Applications: Transport coal, sand, earthwork, building materials etc




3 axle conveyor belt dump trailer is our very popular model, very versatile, mainly suitable for transporting coal, ore, earthwork, construction waste or other bulk goods.

This type of vehicle uses a conveyor belt to unload goods, which is not affected by the transportation environment, is safe and reliable, saves manpower and costs, and has good sealing performance to ensure that the goods do not leak or fall.

Our conveyor belt dump trailer adopts a two-stage hydraulic locking structure, the rear door can be completely closed 100%, the transportation process is more environmentally friendly and will not pollute the environment.

YUHANG factory high-quality mechanical conveyor belt system can increase the unloading speed of goods, improve work efficiency, and create more profit value for you.

3 Axle Conveyor Belt Dump Trailer-YUHANG VEHICLE3 axle conveyor belt dump trailer for sale

3 Axle Conveyor Belt Dump Trailer-YUHANG VEHICLE60 ton crawler type dump semi trailer with best price

3 Axle Conveyor Belt Dump Trailer-YUHANG VEHICLEYUHANG factory brand new crawler cargo transport trailer manufacturer


1. The main beam and compartment of the 3 axle conveyor belt dump trailer is made of high-strength steel plates. The whole vehicle has passed the durability test, and the product quality is more stable and reliable.

2. Strong adaptability, no high requirements on the unloading site, no restrictions on the working height, applicable to different working environments, no need to lift the carriage, and no risk of rollover.

3. The hydraulic system components of the whole vehicle (hydraulic cylinder, multi-way valve, oil pipe, oil pump, etc.) are all world-renowned brands. The hydraulic system is safe and reliable, and the vehicle can be unloaded while moving, with high efficiency.

4. The hydraulic automatic steering device installed inside the vehicle can realize the tilting and shaking of the vehicle body when the unloading is not clean, so as to ensure that there is no residue of the cargo.


Manufacturer: YUHANG 3 Axle Conveyor Belt Dump Trailer

Box Dimension: 9500mm*2500mm*1500mm

Payload: 30-80 ton

Unloading Method: Transport by conveyor belt

Main Beam: Q345B carbon steel, ‘I” type

Frame Beam: upper and lower plate is 14mm and 16mm, web plate 8 mm, height is 500 mm

Box thickness: bottom plate 4mm, side plate 3mm

Axle: 3 axle*13 ton BPW/FUWA brand

Landing Gear: JOST brand 28 ton

King Pin: 2.0 or 3.5 inch

Suspension: heavy duty mechanical suspension

Leaf Spring: 90mm(w)*16mm(t)*10pcs

Tires: 12R22.5, 315/80R22.5

Hydraulic System: HYVA brand

Color/ABS: optional
