5 Axle Semi Low Bed Trailer

The 5 axle semi low bed trailer is made of high-strength steel plate, with strong bearing capacity and good compression resistance, it can effectively ensure the safe transportation of heavy goods.

14800 USD

Model: 5 axle semi low bed trailer

Material: high strength steel plate

Delivery Date: 10-25 days

Application: loading excavators, bulldozers or other machinery




The 5 axle semi low bed trailer is mainly designed for heavy mechanical engineering equipment such as bulldozers, excavators and cranes, as well as other commercial or agricultural vehicles.

The load capacity of this series of lowbed trailer is 100-150 tons, YUHANG brand semi low bed trailer have clear capacity, specification, size, height and configuration.

Our 5 axle semi low bed trailer has a low center of gravity, which has obvious advantages in transporting large and heavy equipment and avoiding cargo damage.

We can provide customers with the most complete lowbed trailer transportation solutions, better suitable for cargo transportation and create economic value.

5 Axle Semi Low Bed Trailer-YUHANG VEHICLE5 axle semi low bed trailer for sale

5 Axle Semi Low Bed Trailer-YUHANG VEHICLE100 ton lowbed trailer with best price

5 Axle Semi Low Bed Trailer-YUHANG VEHICLEChina high quality semi low bed trailer manufacturer—YUHANG


1. Our 5 axle semi low bed trailer have been widely concerned and recognized by customers because of their high strength and durability.

2. The main beam is made of HG60 high-strength tensile steel plate, which has strong bearing capacity.

3. Robotic automatic welding throughout the whole process, with high welding strength, further improving the quality of the 100 ton lowbed trailer.

4. Spray wear-resistant and anti-corrosion topcoat, which lasts for a long time and avoids rusting.

5. Use world-renowned brand parts, maintenance-free and cost-saving.


Dimension: 15500mm*3000mm*3700mm

Loading Capacity: 100-150 tons

Application: transportation of excavators, bulldozers, cranes or other equipment

Main Beam: height 500mm, upper plate 20mm, middle plate 16mm, lower plate 22mm, material Q345B steel

Bottom Platform: 5mm thick checkered plate

Axle: 5 units*FUWA/BPW/other Brand

Rim: 8.0-22.5

Tire: 20 units*10.00R20/11.00R20/12.00R20/12R22.5

Suspension: heavy mechanical suspension

Spring Leaf: 90(w)mmx13(thickness)mm x 10 layers

Kingpin: 2 or 3.5 inch (bolted or welded type)

Landing Gear: JOST brand

Rear Ramp: spring ramp or hydraulic ramp

ABS: optional

Brake Valve: WABCO valve

Light: LED light

Electrical System: 24-volt lighting system

Accessories: 1 set tool box, spare tire carrier

Shipping Terms: bulk carrier, Ro-Ro ship or container
