2 Axle 50 Ton Open Top Trailer

Description

Description：

Our 2 axle 50 ton open top trailer for you. It is widely used in the transportation industry, mainly used to transport bulk goods, such as: grain, cement bags, steel plates, and carton packaging items.

This series of trailer is developed on the basis of flatbed semi trailer, and adopts side wall design structure. The working platform can be used to load containers after installing high-quality twist locks on it.

2 axle open top trailer has a loading capacity of 30-50 tons and the height of the side wall can be customized or designed according to the specific needs of the customers.

YUHANG has different specifications and configurations sidewall semi trailer for you to choose, welcome to you send an inquiry to get an exclusive quotation.

2 axle open top trailer price

50 ton sidewall semi trailer for sale

China famous bulk cargo open top trailer supplier–YUHANG

Advantage：

● 50 ton open top trailer frame is integrally welded by beams and longitudinal beams to ensure an optimal cargo load structure.

● Heavy-duty leaf spring suspension system is used to support the load, absorb vibration energy, and reduce damage to the trailer under heavy load.

● The high-performance accessories of international famous brands are selected, which greatly improves the safety performance and service life of the sidewall semi trailer.

● The whole vehicle is treated with shot blasting and rust removal, and sprayed with polyurethane paint, which is corrosion-resistant, salt-alkali resistant, and has high gloss.

● YUHANG VEHICLE always insists on providing customers with high-quality 2 axle open top trailer for sale.

Specification:

Brand: YUHANG 2 Axle 50 Ton Open Top Trailer

Dimension(L*W*H): 12500x2500x3200mm or customized

Loading Capacity: 50 ton or customized

Founction: transport bulk cargo or 1*40ft container, 2*20ft container

Main Beam: height 500mm, upper plate 14mm, middle plate 8mm, lower plate 16mm, material high tension carbon steel

Side Beam: 16mm or 18mm channel steel

Platform: 3mm-thick checkered plate

Trailer Sidewall: 600-2000mm or customize

Axles: 2 axles*13T/16T*FUWA/BPW brand

Tire: 8 units*12.00R22.5 or 315/80R22.5

Rim: 9.00-22.5 steel wheel rim

Suspension: mechanical suspension

Spring Leaf: 90(w)mmx13(thickness)mmx10 layers or 100mmx12mmx12 layers

King Pin: JOST brand 2.0 or 3.5 inch traction pin

Landing Gear: JOST brand 28t lifting capacity with two speed

Twist Locks: 4/8/12 sets (lifting or screw type)

Brake Valve: WABCO valve

ABS: optional

Light: LED light

Voltage: 24V

Socket: 7-pin Socket (for 7 wire harness)

Painting: 1 layer of anticorrosive primer and 2 layers of top coats

Accessories: one tool box, spare tire carrier

Shipping Terms: bulk carrier, Ro-Ro ship or container

---
