Drop Side Trailer For Sale

Description

Description：

YUHANG is a high-quality drop side trailer for sale manufacturer in China, among Our 60 ton drop side trailer is favored and recognized by customers from many countries.

The 3 axle drop side trailer has a load capacity of 30-80 tons and can transport 20ft, 40ft standard configuration containers and other easily secured bulk cargo.

The side wall of the drop side trailer can be opened and disassembled for easy loading and unloading of bulk goods, and the shape and height of the side panels can be customized for you.

Our bulk cargo sidewall semi trailer has reasonable structure, reliable performance, simple operation and beautiful appearance. Welcome to you send inquiry

60 ton drop side trailer for sale

3 axle sidewall semi trailer price

China famous 30/50/60/80 ton drop side trailer manufacturer

Advantage：

● The main beam is made of high-strength steel plate and is used for loading bulk goods of different weights and containers.

● The main spare parts are processed by advanced equipment to enhance the practicality and flexibility of the drop side trailer.

● The trailer frame adopts automatic robot welding technology, and the solder joints are tight and firm without flaws.

● The whole vehicle is treated with shot blasting to remove rust, which greatly improves the adhesion of paint.

● YUHANG each drop side trailer will go through compression and anti-collision test before delivery to ensure the best quality.

Specification:

Dimension(L*W*H): 12500x2500x3300mm

Loading Capacity: 30-80 tons or customized

Main Beam: height 500mm, upper plate 14mm, middle plate 8mm, lower plate 16mm, material Q345B carbon steel

Side Beam: 16mm or 18mm channel steel

Platform: 3 mm-thick checkered plate

Trailer Sidewall: 1200mm

Axles: 3 axles*13T/16T*FUWA/BPW brand

Tire: 12 units*12.00R22.5 or 315/80R22.5

Rim: 9.00-22.5 or 9.75-22.5 steel wheel rim

Suspension: mechanical suspension

Spring Leaf: 90(w)mmx13(thickness)mmx10 layers or 100mmx12mmx12 layers

King Pin: JOST brand 2.0 or 3.5 inch traction pin

Landing Gear: JOST brand 28t lifting capacity

Twist Locks: 4/8/12 sets (lifting or screw type)

Brake Valve: WABCO valve

ABS: optional

Color: optional

Light: LED light

Voltage: 24V

Socket: 7-pin Socket (for 7 wire harness)

Painting: 1 layer of anticorrosive primer and 2 layers of top coats

Accessories: one tool box, spare tire carrier

Shipping Terms: bulk carrier, Ro-Ro ship or container

---
