40000 Liter Fuel Tanker Trailer

13600 USD

40000 liter fuel tanker trailer has different compartments to transport different kinds of liquids at the same time. This can improve transportation efficiency and save costs.

Model: 40000 liter fuel tanker trailer

Material: carbon steel

Delivery Date: 10-25 days

Application: transport gasoline, diesel, crude oil, lubricating oil, coal tar, palm oil, etc.

Enquiry

Description

Description:

40,000 liter fuel tanker trailer can be used to load different liquid substances such as edible oil, gasoline, diesel, water, palm oil, bitumen, etc. Our fuel tanker are available in a variety of materials and designs.

YUHANG VEHICLE fuel tanker trailer adopts advanced design concept and technological innovation. The tank body is resistant to corrosion, deformation, earthquake and turbulence, ensuring safe and reliable transportation.

We offer fuel tanker trailer for sale in carbon steel, stainless steel and aluminum alloy material. The volume of the tank body can be customized, 40,000 liters, 42,000 liters, 50,000 liters, and up to 90,000 liters. Different compartments can be used to hold different liquids.

The whole vehicle can be equipped with high-quality mechanical suspension, which has strong bearing capacity and is suitable for different complex road conditions.

40000 Liter Fuel Tanker Trailer-YUHANG VEHICLE40000 liter fuel tanker trailer for sale

40000 Liter Fuel Tanker Trailer-YUHANG VEHICLE3 axle tanker trailer with the best price

40000 Liter Fuel Tanker Trailer-YUHANG VEHICLEChina first class fuel tanker trailer maufacturer

Advantage:

The outer surface of the 40,000 liters fuel tanker trailer is made of high-grade polyurethane paint, and the interior is treated with anti-corrosion; to ensure that the service life of the tank body is more than 15 years.

After the overall welding of the tank body, the shot blasting technology is used to remove the rust. The maintenance cost is low, the appearance is lasting and bright, and it is easy to clean.

The 40,000 liter fuel tanker trailer for sale has a low center of gravity, does not contain flammable materials, has low static accumulation, and makes the vehicle run more safely, stably and reliably; it currently has a good record of safe operation.

YUHANG VEHICLE can customize fuel tankers according to customer requirements. Chassis, tank body color optional, metallic paint and other color paint, tanker optional, optional flow meter, tool box, etc.

40,000 liter fuel tanker is manufactured and produced in strict accordance with international industry standards, eliminating fake and shoddy products and ensuring the safety of dangerous goods transportation.

Specification:

Dimension: 12,000mm*2,600mm*3,700mm

Tare Weight: about 8,000kg

Total Volume(L): 40,000 liter

Main Beams: Q345 carbon steel material

Tank Body Material: Q235 carbon steel

End plate: Q235 carbon steel

Manhole Cover: carbon steel

Bottom Valve: aluminum API pneumatic

Discharging Valve: diameter is 3 or 4 inch

Compartments: one compartment or customizable

Discharging Pipe: 4 inch rubber hose, 2 pcs, 6m/each

Axle: 3 axle*13T, BPW/FUWA brand

Landing Gear: JOST brand

King pin: JOST 2.0 or 3.5 inch bolt-in king pin

Suspension: mechanical suspension

Leaf Spring: 90(w)mmx13(thickness)

Braking System: WABCO brand

Rim: 9.00-22.5

Tire: 12 units*12.00R22.5

ABS: optional

Painting: 1 layer of anticorrosive primer and 2 layer of top coats

Accessories: one standard tool box

Shipping Terms: by bulk carrier or 45ft HQ container

All the accessories we choose are purchased and processed through formal channels. To ensure the highest quality and working performance of fuel tank semi trailer.

40000 Liter Fuel Tanker Trailer-YUHANG VEHICLESteel Plate/Axle/Tires/Leaf Springs/Suspension/Landing Gear

Choose YUHANG:

The fuel tanker trailer tank body we sell use advanced large-scale special automatic welding machinery and equipment. The tank body is formed in one step, which reduces the number of welding times and improves the safety performance of the tank body by at least 30%. After the tank body and other accessories are welded, they will be sanded and painted again to make the tanker semi trailer stronger, safer, more durable, more economical and environmentally friendly.

At the same time, we have advanced testing equipment to analyze and study the composition, hardness, quality, and physical phase of metal at any time to ensure that the processed materials fully meet the standards. YUHANG factory will also inspect and correct weld defects, paint thickness, tank body stress, and penetration to ensure that the trailer is 100% problem-free. The processing conditions under strict procedures make the transportation center of gravity of the fuel tanker trailer more stable and the sales price more stable and reliable, which greatly increases the later working time of the tank truck trailers.

40000 Liter Fuel Tanker Trailer-YUHANG VEHICLE

Fuel Tank Semi Trailer Manufacturing Process:

1. Design: The manufacturing factory should carry out the design, configuration, structure and material layout of the tanker trailer based on the actual transportation needs of the customer and market regulations. At this time, factors such as: the trailer’s load, cargo type, usage environment, tank body pressure, etc. need to be comprehensively considered.

2. Manufacturing: This process requires the production of vehicle frames, tank body, manhole covers, wave protection plates and other components according to design drawings. At this time, various professional equipment will be used to perform cutting, stamping, riveting, welding and other related operations to ensure that the structure of the trailer is strong and stable.

3. Assembly: At this stage, the manufactured components need to be installed together with axles, tires, leaf springs, tool boxes, braking systems, lights, etc. During the assembly process, the relationship between each component needs to be considered to ensure the overall performance and work efficiency of the trailer.

4. Inspection: Finally, a comprehensive quality inspection is required on the completed oil tank semi trailer to ensure the safety and reliability of the trailer. The inspection content mainly includes: whether the appearance, size and installation of the trailer meet the requirements, and whether the various functions are normal.

40000 Liter Fuel Tanker Trailer-YUHANG VEHICLE

Fuel Tanker Trailer Video:

40000 Liter Fuel Tanker Trailer-YUHANG VEHICLE

Do you need to know more details or features about our fuel tanker trailers and oil tank semi trailers? Please feel free to contact YUHANG or directly fill in the inquiry information in the form below.
