40ft Skeletal Semi Trailer

Description

Description：

40ft skeletal semi trailer is mainly used for standard container loading and transportation in application scenarios such as: ships, ports, shipping lines, roads, and transfer stations.

Our container chassis trailers have a reasonable design structure, light weight, large loading capacity, uniform force, can be used repeatedly for a long time, and have low maintenance costs.

The 40ft skeletal trailer can quickly realize the mechanized loading and unloading of containers, reduce cargo damage and waiting time, save labor costs, and improve work efficiency.

YUHANG has 2 axle, 3 axle, 4 axle, 20 feet, 40 feet, 45 feet and 48 feet container chassis trailers for sale, with a loading capacity of 30-80 ton for you to choose.

3 axle 40ft skeletal semi trailer for sale

Advantage：

● The main beam of the 40ft skeletal semi trailer is made of high-strength steel plate material, which makes it have higher loading capacity and longer service life.

● The whole vehicle adopts robot automatic tracking welding technology to ensure that the container chassis trailer is more durable and stronger.

● Using world-renowned brand spare parts, saving maintenance time and cost for customers.

● Electrophoretic powder spraying and baking varnish technology, the whole vehicle has full gloss, corrosion resistance and beautiful appearance.

● The brake system is equipped with WABCO brand to improve the braking performance of the vehicle.

Specification:

Manufacturer: YUHANG 40ft Skeletal Semi Trailer

Dimension: 12500x2500x1500mm

Loading Capacity: 30-80t

Application: transport 20ft/40ft container

Main Beam: height 500mm, upper plate 14mm, middle plate 8mm, bottom plate 16mm, Q345B carbon steel

Axles: 3 axles, 13T/14/16T, FUWA/BPW/ brand

Tire: 12 units, 12.00R22.5 or 315/80R22.5

Rim: 9.00-22.5 or 9.75-22.5

Suspension: mechanical suspension or air suspension

Spring Leaf: 90(w)mmx13(thickness)mmx10 layers or 100mmx12mmx12 layers

King Pin: JOST brand 50# or 90# (bolted or welded)

Landing Gear: JOST brand 28 ton, double speed

Twist Locks: 4,8,12 sets (lifting or screw type)

Brake System: WABCO brake valve

ABS: optional

Color: optional

Light: LED light

Voltage: 24V

Socket: 7-pin Socket (for 7 wire harness)

Painting: polyurethane anti-corrosion paint

Accessories: one standard tool box, spare tire carrier

Shipping Terms: bulk carrier, Ro-Ro ship or 45ft HQ container

---
