3 Line 6 Axle Low Loader Trailer

Description

Description：

YUHANG brand new 3 line 6 axle low loader trailer can be used to transport agricultural machinery equipment, engineering vehicles, mechanical plates, large building materials, etc.

We also have other types and configurations of heavy-duty lowbed semi trailer for sale, which have better load capacity and application conditions.

At the same time, We have 2 axle/3 axle/4 axle lowbed trailer for sale, which can load 30-100 ton bulk cargo. The quality is durable and can adapt to more complex road conditions.

The length and width of the 120 tons heavy duty low loader trailer can be customized to meet the different transportation requirements of customers, make it better for customers to play practical value.

120 tons heavy duty low loader trailer for sale

YUHANG 3 line 6 axle low loader trailer price

China 60/80/100/120 tons lowbed semi trailer manufacturer

Advantage：

⬤ The main beam of the 3 line 6 axle low loader trailer is integrally cut with high tensile strength steel plate, which has strong bearing capacity and long service life.

⬤ The 120 tons heavy duty low loader trailer carrying platform adopts 5mm thick anti-slip and wear-resistant checkered plate to ensure the safety and stability of the transported goods.

⬤ The high-strength wear-resistant load-bearing ramp ensures that heavy equipment will not be deformed or broken after repeated loading and unloading.

⬤ Spraying polyurethane paint, high gloss, corrosion resistance, more full body color.

⬤ Using world-renowned brand components to ensure the highest quality of work and save investment costs.

Specification:

Dimension: 16500mm*3500mm*3800mm

Loading Capacity: 120 tons

Application: transportation of excavators, bulldozers, cranes

Main Beam: height 500mm, upper plate 20mm, middle plate 16mm, lower plate 22mm, material Q345B steel

Bottom Platform: 5mm thick checkered plate

Axle: 6 axles/FUWA/BPW/other Brand

Rim: 8.0-22.5

Tire: 24 units/10.00R20/11.00R20/12.00R20/12R22.5

Suspension: heavy duty mechanical suspension

Spring Leaf: 90(w)mmx13(thickness)mmx 10 layers

King Pin: 2 or 3.5 inch (bolted or welded type)

Landing Gear: JOST brand

Rear Ramp: spring ramp or hydraulic ramp

ABS: optional

Brake Valve: WABCO valve

Light: LED light

Electrical System: 24-volt lighting system

Accessories: one tool box, spare tire carrier

Shipping Terms: bulk carrier, Ro-Ro ship or container

---
