3 Axle Tipper Trailer Price

Description

Description：

3 axle tipper trailer price is better than other factories, it is widely used in quarries, construction sites and mines, and usually works in conjunction with excavators, loaders, crawler conveyors.

This series of dump semi trailers are mainly used to transport bulk goods, such as: gravel, coal, ore, grain, earthwork, with large loading capacity, strong output performance and durability.

The structure of the 3 axle tipper trailer includes a chassis, a box body and a hydraulic lifting system. The working principle is that the PTO supplies oil to the oil cylinder, the hanging box is lifted to the designed angle, and the cargo slides out from the box body.

YUHANG can customize hydraulic dump semi trailer according to your special transportation needs, with loading capacities of 40 tons, 60 tons, 80 tons, 100 tons.

3 axle tipper trailer price

80 ton dump semi trailer for sale

China high quality tipper trailer manufacturer

Advantage：

1. YUHANG brand 3 axle tipper trailer for sale, it is made of high-strength Q345 steel, which makes it have a stronger loading capacity and is more durable.

2. The frame of the tipper trailer is welded by fully automatic tracking submerged arc, so that the dump trailer can reach the best working condition and prolong the service life.

3. High-quality HYVA hydraulic cylinder is adopted, which has strong lifting capacity, safety and stability, and effectively improves loading and unloading efficiency.

4. Well-known brands of axles, suspensions, tires and braking systems have excellent performance and are reliable in use, ensuring that the vehicle has good operating data.

5. All spare parts are shot blasted and polished, electrophoretic spray powder, no fading, no falling off, corrosion resistance.

Specification:

Model: 3 Axle Tipper Trailer Price

Dimension: 9500mmx2800mm x3900mm or customized

Main Beam: height 500mm, upper plate 14mm, middle plate 8mm, lower plate 16mm, material Q345 carbon steel

Bottom Platform: 6mm thick checkered plate

Sidewall: 4mm

Lifting System: HYVA lifting cylinder

Axle: 3 axle, 13T/16T, FUWA/BPW brand

Rim: 8.0-20 or 9.00-20

Tire: 12 units, 8.25R20/10.00R20/11.00R20/12R22.5

Suspension: heavy duty mechanical suspension

Spring Leaf: 90(w)mmx13(thickness)mmx10 layers

King Pin: JOST brand 2.0 or 3.5 inch(bolted or welded type)

Landing Gear: JOST brand 28 tons, two speed

ABS: optional

Brake System: WABCO valve

Light: LED light

Voltage: 24V

Socket: 7-pin Socket (for 7 wire harness)

Painting: polyurethane anti-corrosion paint

Accessories: one standard tool box, spare tire carrier

Shipping Terms: bulk carrier, Ro-Ro ship

---
