Triaxle Dumper Semi Trailer

Description

Description：

Triaxle dumper semi trailer for sale is commonly used to transport construction materials (sand, earthwork, engineering plastics), coal, iron ore or other bulk cargos.

Our tipper trailer with HYVA hydraulic cylinder is a special-purpose vehicle, which realizes automatic unloading by lifting the box body. This kind of trailer is easy to operate and saves manpower.

YUHANG dumper semi trailer has different loading capacity, such as: 40 ton/50 ton/60 ton/80 ton, we can customize different models of tipper trailer according to your special needs.

We have u shaped tipper trailer for sale with loading volumes of 24cbm, 30cbm, 35cbm, 45cbm for you to choose, and they are all of the highest quality.

Triaxle dumper semi trailer for sale

50 ton tipper trailer with the best price

China famous 30/50/60/80 ton dump trailer supplier

Advantage：

1. The triaxle dumper semi trailer for sale is made of high-strength steel plates, which has a strong loading capacity and can adapt to more harsh and complex road conditions.

2. Use wear-resistant thick ribs to reinforce the boxes on both sides to reduce the impact of goods and prolong the service life of the tipper trailer.

3. Spray high-quality polyurethane paint to prevent the trailer from rusting and have a beautiful appearance.

4. YUHANG brand dumper semi trailer is subjected to force test analysis and compression performance tests before delivery to ensure that they are in the best working condition.

Specification:

Model: Triaxle Dumper Semi Trailer For Sale

Dimension: 9500mmx2800mm x3900mm

Main Beam: height 500mm, upper plate 14mm, middle plate 8mm, lower plate 16mm, material T700 steel

Bottom Platform: 6 thick checkered plate

Sidewall: 4mm

Lifting System: HYVA lifting cylinder

Axle: 13T/16T, FUWA/BPW brand

Rim: 8.0-20 or 9.00-20

Tire: 8.25R20/10.00R20/11.00R20/12R22.5

Suspension: heavy duty mechanical suspension

Spring Leaf: 90(w)mmx13(thickness)mmx10 layers

King Pin: JOST brand 2.0 or 3.5 inch (bolted or welded type)

Landing Gear: JOST brand

ABS: optional

Color: optional

Brake System: WABCO valve

Light: LED light

Voltage: 24V

Socket: 7-pin Socket (for 7 wire harness)

Painting: polyurethane anti-corrosion paint

Accessories: one standard tool box, spare tire carrier

Shipping Terms: bulk carrier, Ro-Ro ship

---
